Tactical Bulletproof Military Helmet Ballistic Protective Army Helmet M88

Product name

Technology

Bulletproof  helmet FDK01-II type

Color

(Can be customized according to customer requirements)

99-type police uniform dark blue or black

Dimension

Length:246mm * Width: 225mm * Height: 171mm

Product structure

The helmet consists of helmet shell, chin strap and helmet top suspension system.

Material quality

2.0MM bulletproof steel plate

Weight

1.96kg (test results)

Chin belt device

The 45KG weight was hung in the center of the mandibular band. The attachment did not break or slip off within 3 minutes. The emergency trip was not disengaged and damaged.

rigid test

Maximum deformation 10.5mm, residual deformation 4.3mm

flame retardancy

The flame of the helmet will self-extinguishes within 5s

Shooting distance

5 meters

Shooting position

Front, back, left, right, top of the head

Bullet speed

421M/S-441M/S

Bulletproof performance

The helmet can effectively prevent the shooting of the 54 type 7.62mm pistol 51 type 7.62 mm pistol bullet (lead heart) within the specified range,the bulletproof level is two-level, shooting the bullet-proof helmet at 5M distance, the helmet should block the warhead in the case of 5 effective hits, The bullet mark height of the helmet shell is not more than 25MM, and there is no part falling off in the suspension buffer system after the test.

Environmental suitability

Immersion (maximum bullet height 7.5MM on the back)

High temperature (maximum bullet height 7.5MM on the back)

Low temperature (maximum bullet height 6.5MM on the back)

No cracks on the surface after the test Foaming Stratification can maintain secondary ballistic performance.

Operative norm

<< GA293-2001 bulletproof helmets and masks >>

Packing specification

49*48*28CM/CTN,10pcs/CTN
